Hello Does anyone have a flowchart on how the Quadrafire Mt. Vernon AE works. I am having a problem with the igniter circut. I thought it was that thw igniter had gone out. I just ordered a new one and insralled it. No change. So i measured the ohms on old one and new one they were almost identical. Tried to start again and measured voltage going to igniter. Checked fuse and it was good. Voltage would go to relay on board but not comming out. Tried several times but relay never switches. Is there a sensor that would cause stove not to turn on igniter?
Flow chart
- Thread starter SABreiden1
- Start date
-
Active since 1995, Hearth.com is THE place on the internet for free information and advice about wood stoves, pellet stoves and other energy saving equipment.
We strive to provide opinions, articles, discussions and history related to Hearth Products and in a more general sense, energy issues.
We promote the EFFICIENT, RESPONSIBLE, CLEAN and SAFE use of all fuels, whether renewable or fossil. -
Super Cedar firestarters 30% discount Use code Hearth2024 Click here
Don't know about a flow chart but here is a wiring diag
www.manualslib.com
Wiring Schematic - Quadra-Fire MT VERNON Owner's Manual [Page 37]
Quadra-Fire MT VERNON Manual Online: Wiring Schematic. Figure 37.1 August 13, 2018 7036-187M MT. VERNON AE INSERT...
