Installing the Forever Flex Super Wrap Insulation Kit

Super Wrap Liner Insulation Kit Components



For all installations:
Leave the top 4" that will extend above the chimney unwrapped.
If the wrapped liner will be a tight fit in the flue, trim wrap to the exact circumferance of the liner

Standard Installations:
Super Wrap on Wood Stove Liner Diagram
Wrap The Entire Length

Fireplace Installations:
Super Wrap on Wood Insert Liner Diagram Super Wrap on Wood Hearth Stove Liner Diagram
Omit Wrap Below Damper

Standard Installs, Step 1: Roll out wrap, foil side down
Standard Super Wrap Install, Step 1		Fireplace Installs, Step 1: Roll out wrap, cut to length
Insert Liner Super Wrap Install, Step 1
Standard Installs, Step 2: Coat with spray adhesive
Standard Super Wrap Install, Step 2		Fireplace Installs, Step 2: Coat with spray adhesive
Insert Liner Super Wrap Install, Step 2
Standard Installs, Step 3: Lay liner down center
Standard Super Wrap Install, Step 3		Fireplace Installs, Step 3: Lay liner down center
Insert Liner Super Wrap Install, Step 3
Standard Installs, Step 4: Roll wrap around liner: trim any overlap
Standard Super Wrap Install, Step 4		Fireplace Installs, Step 4: Roll wrap around liner: trim any overlap
Insert Liner Super Wrap Install, Step 4
Standard Installs, Step 5: Seal seam with metal tape
Standard Super Wrap Install, Step 5		Fireplace Installs, Step 5: Seal seam with metal tape
Insert Liner Super Wrap Install, Step 5
Standard Installs, Step 6: Slide liner into mesh sleeve
Standard Super Wrap Install, Step 6		Fireplace Installs, Step 6: Slide liner into mesh sleeve
Insert Liner Super Wrap Install, Step 6
Standard Installs, Step 7: Tighten pipe clamps onto both ends
Standard Super Wrap Install, Step 7		Fireplace Installs, Step 7: Tighten pipe clamps onto both ends
Insert Liner Super Wrap Install, Step 7
